Numerous national and international approvals and qualifications in accordance with a variety of application standards make the W-series a universal connection solution, especially in harsh conditions. The screw connection has long been an established connection element to meet exacting demands in terms of reliability and functionality. And our W-Series is still setting standards. Whatever your requirements for the panel: our screw connection system with patented clamping yoke technology ensures the ultimate in contact safety. You can use both screw-in and plug-in cross-connections for potential distribution. Two conductors of the same diameter can also be connected in a single terminal point in accordance with UL1059. The screw connection has long been an established connection element to meet exacting demands in terms of reliability and functionality. And our W-Series is still setting standards. Weidmulle‘s W series terminal blocks save space， Small “W-Compact” size saves space in the panel. Two conductors can be connected for each contact point.



Version	W-Series, Initiator/actuator terminal, Rated cross-section: 2.5 mm², Screw connection
Order No.	1784180000
Type	DLD 2.5 DB
GTIN (EAN)	4032248189854
Qty.	50 pc(s).



Depth	48.5 mm
Depth (inches)	1.909 inch
Depth including DIN rail	49 mm
Height	82.5 mm
Height (inches)	3.248 inch
Width	6.2 mm
Width (inches)	0.244 inch
Net weight	15.84 g



Order No.:6269250000	Type: DLD 2.5 BL
Order No.: 1783790000	Type: DLD 2.5/PE DB
