Whatever your requirements for the panel: our screw connection system with patented clamping yoke technology ensures the ultimate in contact safety. You can use both screw-in and plug-in cross-connections for potential distribution.Two conductors of the same diameter can also be connected in a single terminal point in accordance with UL1059.The screw connection has long been an established connection element to meet exacting demands in terms of reliability and functionality. And our W-Series is still setting standards. Space saving, Small W-Compact" size saves space in the panel，two conductors can be connect for each contact point Our promise The high reliability and variety of designs of the terminal blocks with clamping yoke connections make planning easer and optimises operational safety. Klippon@ Connect provides a proven response to a range of different requirements.

Version	Feed-through terminal, Screw connection, 240 mm², 1000 V, 415 A, dark beige
Order No.	1802780000
Type	WDU 240
GTIN (EAN)	4032248313723
Qty.	2 pc(s).

Depth	123.7 mm
Depth (inches)	4.87 inch
Depth including DIN rail	124 mm
Height	100 mm
Height (inches)	3.937 inch
Width	36 mm
Width (inches)	1.417 inch
Net weight	472.5 g

Order No.: 1822210000

Type: WDU 240 BL
