Whatever your requirements for the panel: our screw connection system with patented clamping yoke technology ensures the ultimate in contact safety. You can use both screw-in and plug-in cross-connections for potential distribution.Two conductors of the same diameter can also be connected in a single terminal point in accordance with UL1059.The screw connection has long been an established connection element to meet exacting demands in terms of reliability and functionality. And our W-Series is still setting standards. Space saving, Small W-Compact" size saves space in the panel，two conductors can be connect for each contact point Our promise The high reliability and variety of designs of the terminal blocks with clamping yoke connections make planning easer and optimises operational safety. Klippon@ Connect provides a proven response to a range of different requirements.

Version	Feed-through terminal, Screw connection, 120 mm², 1000 V, 269 A, dark beige
Order No.	1024500000
Type	WDU 120/150
GTIN (EAN)	4008190164768
Qty.	10 pc(s).

Depth	117 mm
Depth (inches)	4.606 inch
Depth including DIN rail	125.5 mm
Height	132 mm
Height (inches)	5.197 inch
Width	32 mm
Width (inches)	1.26 inch
Net weight	508.825 g

Order No.: 1024580000	Type: WDU 120/150 BL
Order No.:1024550000	Type:1024550000
Order No.:1026600000	Type: WDU 120/150/5
Order No.: 1032400000	Type: WDU 120/150/5 N
