Whatever your requirements for the panel: our screw connection system with patented clamping yoke technology ensures the ultimate in contact safety. You can use both screw-in and plug-in cross-connections for potential distribution.Two conductors of the same diameter can also be connected in a single terminal point in accordance with UL1059.The screw connection has long been an established connection element to meet exacting demands in terms of reliability and functionality. And our W-Series is still setting standards. Space saving, Small W-Compact" size saves space in the panel，two conductors can be connect for each contact point Our promise The high reliability and variety of designs of the terminal blocks with clamping yoke connections make planning easer and optimises operational safety. Klippon@ Connect provides a proven response to a range of different requirements.

Version	Feed-through terminal, Screw connection, 10 mm², 800 V, 57 A, dark beige
Order No.	1042400000
Type	WDU 10/ZR
GTIN (EAN)	4032248285655
Qty.	50 pc(s)

Depth	49 mm
Depth (inches)	1.929 inch
Depth including DIN rail	49.5 mm
Height	70 mm
Height (inches)	2.756 inch
Width	9.9 mm
Width (inches)	0.39 inch
Net weight	22.234 g

Order No.: 1020300000	Type: WDU 10
Order No.:1020380000	Type:WDU 10 BL
Order No.:2821630000	Type: WDU 10 BR
Order No.: 1833350000	Type: WDU 10 GE
