Whatever your requirements for the panel: our screw connection system with patented clamping yoke technology ensures the ultimate in contact safety. You can use both screw-in and plug-in cross-connections for potential distribution.Two conductors of the same diameter can also be connected in a single terminal point in accordance with UL1059.The screw connection has long been an established connection element to meet exacting demands in terms of reliability and functionality. And our W-Series is still setting standards. Space saving, Small W-Compact" size saves space in the panel，two conductors can be connect for each contact point Our promise The high reliability and variety of designs of the terminal blocks with clamping yoke connections make planning easer and optimises operational safety. Klippon@ Connect provides a proven response to a range of different requirements.

Version	Feed-through terminal, Screw connection, 10 mm², 1000 V, 57 A, dark beige
Order No.	1020300000
Type	WDU 10
GTIN (EAN)	4008190068868
Qty.	50 pc(s)

Depth	46.5 mm
Depth (inches)	1.831 inch
Depth including DIN rail	47 mm
Height	60 mm
Height (inches)	2.362 inch
Width	9.9 mm
Width (inches)	0.39 inch
Net weight	16.9 g

Order No.: 1020380000	Type: WDU 10 BL
Order No.:2821630000	Type:WDU 10 BR
Order No.:1833350000	Type: WDU 10 GE
Order No.: 1833340000	Type: WDU 10 GN
