Whatever your requirements for the panel: our screw connection system with patented clamping yoke technology ensures the ultimate in contact safety. You can use both screw-in and plug-in cross-connections for potential distribution.Two conductors of the same diameter can also be connected in a single terminal point in accordance with UL1059.The screw connection has long been an established connection element to meet exacting demands in terms of reliability and functionality. And our W-Series is still setting standards. Space saving, Small W-Compact" size saves space in the panel，two conductors can be connect for each contact point Our promise The high reliability and variety of designs of the terminal blocks with clamping yoke connections make planning easer and optimises operational safety. Klippon@ Connect provides a proven response to a range of different requirements.

Version	Double-tier terminal, Screw connection, 4 mm², 800 V, 32 A, dark beige
Order No.	1041900000
Type	WDK 4N
GTIN (EAN)	4032248138814
Qty.	50 pc(s).

Depth	63.25 mm
Depth (inches)	2.49 inch
Depth including DIN rail	64.15 mm
Height	60 mm
Height (inches)	2.362 inch
Width	6.1 mm
Width (inches)	0.24 inch
Net weight	12.11 g

Order No.: 1041980000	Type: WDK 4N BL
Order No.:1041950000	Type:WDK 4N DU-PE
Order No.:1068110000	Type: WDK 4N GE
Order No.: 1041960000	Type: WDK 4N OR
