Whatever your requirements for the panel: our screw connection system with patented clamping yoke technology ensures the ultimate in contact safety. You can use both screw-in and plug-in cross-connections for potential distribution.Two conductors of the same diameter can also be connected in a single terminal point in accordance with UL1059.The screw connection has long been an established connection element to meet exacting demands in terms of reliability and functionality. And our W-Series is still setting standards. Space saving, Small W-Compact" size saves space in the panel，two conductors can be connect for each contact point Our promise The high reliability and variety of designs of the terminal blocks with clamping yoke connections make planning easer and optimises operational safety. Klippon@ Connect provides a proven response to a range of different requirements.

Version	Feed-through terminal, Double-tier terminal, Screw connection, 10 mm², 800 V, 57 A, dark beige
Order No.	1186740000
Type	WDK 10
GTIN (EAN)	4050118024616
Qty.	50 pc(s).

Depth	69 mm
Depth (inches)	2.717 inch
Depth including DIN rail	69.5 mm
Height	85 mm
Height (inches)	3.346 inch
Width	9.9 mm
Width (inches)	0.39 inch
Net weight	39.64 g

Order No.:1186750000	Type:WDK 10 BL
Order No.:1415520000	Type:WDK 10 DU-N
Order No.:1415480000	Type: WDK 10 DU-PE
Order No.: 1415510000	Type: WDK 10 L
