Version	Power supply, switch-mode power supply unit, 24 V
Order No.	1478200000
Type	PRO MAX3 960W 24V 40A
GTIN (EAN)	4050118286076
Qty.	1 pc(s).



Depth	150 mm
Depth (inches)	5.905 inch
Height	130 mm
Height (inches)	5.118 inch
Width	140 mm
Width (inches)	5.512 inch
Net weight	3,400 g



Order No.	Type
1478170000	PRO MAX3 120W 24V 5A
1478180000	PRO MAX3 240W 24V 10A
1478190000	PRO MAX3 480W 24V 20A
1478200000	PRO MAX3 960W 24V 40A



AC failure bridging time @ Inom	min. 20 ms
Current limiting	> 120% IN
Degree of efficiency	93.5%
Derating	> 60°C / 75% @ 70°C
Earth leakage current, max.	3.5 mA
Housing version	Metal, corrosion resistant
MTBF According to Standard SN 29500 Operating time (hours), min. 642 kh Ambient temperature 25 °C Input voltage 400 V Output power 960 W Duty cycle 100 %
Mounting position, installation notice	Horizontal on TS35 mounting rail. 50 mm of clearance at top & bottom for air circ. Can mount side by side with no space in between.
Operating temperature	-25 °C...70 °C
Power loss, idling	9 W
Power loss, nominal load	66.7 W
Protection against reverse voltages from the load	30…35 V DC
Protection degree	IP20
Short-circuit protection	Yes
Start-up	≥ -40 °C
Status indication	LED red/green and relay (≥21.6 V DC LED green, relay on/ ≤20.6 LED red, relay off)
Surge voltage category	III
