Version	Power supply, switch-mode power supply unit, 24 V
Order No.	1478120000
Type	PRO MAX 180W 24V 7,5A
GTIN (EAN)	4050118286045
Qty.	1 pc(s).



Depth	125 mm
Depth (inches)	4.921 inch
Height	130 mm
Height (inches)	5.118 inch
Width	50 mm
Width (inches)	1.969 inch
Net weight	950 g



Order No.	Type
1478100000	PRO MAX 72W 24V 3A
1478210000	PRO MAX 70W 5V 14A
1478220000	PRO MAX 72W 12V 6A
1478230000	PRO MAX 120W 12V 10A
1478110000	PRO MAX 120W 24V 5A
1478120000	PRO MAX 180W 24V 7,5A
1478130000	PRO MAX 240W 24V 10A
1478240000	PRO MAX 240W 48V 5A
1478140000	PRO MAX 480W 24V 20A
1478250000	PRO MAX 480W 48V 10A
1478150000	PRO MAX 960W 24V 40A
1478270000	PRO MAX 960W 48V 20A



AC failure bridging time @ Inom	min. 20 ms
Current limiting	> 120% IN
Degree of efficiency	91.5%
Derating	> 60°C / 75% @ 70°C
Earth leakage current, max.	3.5 mA
Housing version	Metal, corrosion resistant
MTBF According to Standard SN 29500 Operating time (hours), min. 1.4 Mh Ambient temperature 25 °C Input voltage 230 V Output power 180 W Duty cycle 100 %
Mounting position, installation notice	Horizontal on TS35 mounting rail. 50 mm of clearance at top & bottom for air circ. Can mount side by side with no space in between.
Operating temperature	-25 °C...70 °C
Power loss, idling	1.8 W
Power loss, nominal load	16.7 W
Protection against reverse voltages from the load	30…35 V DC
Protection degree	IP20
Short-circuit protection	Yes
Start-up	≥ -40 °C
Status indication	LED red/green and relay (≥21.6 V DC LED green, relay on/ ≤20.6 LED red, relay off)
Surge voltage category	III
