| AC failure bridging time @ Inom | min. 20 ms |
| Current limiting | > 120% IN |
| Degree of efficiency | 89% |
| Derating | > 60°C / 75% @ 70°C |
| Earth leakage current, max. | 3.5 mA |
| Housing version | Metal, corrosion resistant |
| MTBF | | According to Standard | SN 29500 | | Operating time (hours), min. | 1.5 Mh | | Ambient temperature | 25 °C | | Input voltage | 230 V | | Output power | 120 W | | Duty cycle | 100 % | | |
| Mounting position, installation notice | Horizontal on TS35 mounting rail. 50 mm of clearance at top & bottom for air circ. Can mount side by side with no space in between. |
| Operating temperature | -25 °C...70 °C |
| Power loss, idling | 1.2 W |
| Power loss, nominal load | 14.8 W |
| Protection against reverse voltages from the load | 30…35 V DC |
| Protection degree | IP20 |
| Short-circuit protection | Yes |
| Start-up | ≥ -40 °C |
| Status indication | LED red/green and relay (≥21.6 V DC LED green, relay on/ ≤20.6 LED red, relay off) |
| Surge voltage category | III |
