| AC failure bridging time @ Inom | > 25 ms at 3 x 500 V AC / > 20 ms at 3 x 400 V AC |
| Degree of efficiency | 90% |
| Earth leakage current, max. | 3.5 mA |
| Housing version | Metal, corrosion resistant |
| Indication | Green LED (Uoutput > 21.6 V DC), Yellow LED (loutput > 90 % IRated typ. ), red LED (overload, overtemperature, short-circuit, Uoutput < 20.4 V DC) |
| MTBF | | According to Standard | SN 29500 | | Operating time (hours), min. | 1.7 Mh | | Ambient temperature | 25 °C | | Input voltage | 400 V | | Output power | 240 W | | Duty cycle | 100 % | | According to Standard | SN 29500 | | Operating time (hours), min. | 776 kh | | Ambient temperature | 40 °C | | Input voltage | 400 V | | Output power | 240 W | | Duty cycle | 100 % | | |
| Max. perm. air humidity (operational) | 5 %…95 % RH |
| Mounting position, installation notice | on terminal rail TS 35 |
| Operating temperature | -25 °C...70 °C |
| Power factor (approx.) | > 0.55 @ 3 x 500 V AC / > 0.65 @ 3 x 400 V AC |
| Power loss, idling | 5 W |
| Power loss, nominal load | 95 W |
| Protection against over-heating | Yes |
| Protection degree | IP20 |
| Short-circuit protection | Yes |
