Weidmuller PRO DCDC 480W 24V 20A 2001820000 DC/DC Converter Power Supply

Weidmuller PRO DCDC series is DC/DC converter power supply. The integrated ORing MOSFET reliably decouples possible internal short circuits. It allows direct parallel connection of ACDC and DCDC converters of the PROtop series for redundancy purposes or to increase power. This makes the use of the otherwise common diode or redundancy modules obsolete. Furthermore, PROtop DCDC converters feature the powerful DCL technology – and their communication module allows full data transparency and remote control.

Products Details


Version DC/DC converter, 24 V
Order No. 2001820000
Type PRO DCDC 480W 24V 20A
GTIN (EAN) 4050118384000
Qty. 1 pc(s).

Depth 120 mm
Depth (inches) 4.724 inch
Height 130 mm
Height (inches) 5.118 inch
Width 75 mm
Width (inches) 2.953 inch
Net weight 1,300 g

Order No. Type
2001800000 PRO DCDC 120W 24V 5A
2001810000 PRO DCDC 240W 24V 10A
2001820000 PRO DCDC 480W 24V 20A

AC failure bridging time @ Inom > 10 ms @ 24 V DC
Clip-in foot metal
Current limiting 150% Iout
Degree of efficiency typ. > 93%
Housing version Metal, corrosion resistant
Humidity 5...95 %, no condensation
MTBF
According to Standard SN 29500
Operating time (hours), min. 1,480,000 h
Ambient temperature 25 °C
Input voltage 24 V
Output power 120 W
Duty cycle 100 %

According to Standard SN 29500
Operating time (hours), min. 683,000 h
Ambient temperature 40 °C
Input voltage 24 V
Output power 120 W
Duty cycle 100 %


Max. perm. air humidity (operational) 5 %…95 % RH
Mounting position, installation notice Horizontal on TS35 mounting rail. 50 mm of clearance at top & bottom for air circ. Can mount side by side with no space in between., 50 mm clearance at top and bottom for free air circulation, mountable side by side without clearance
Operating temperature -25 °C...70 °C
Power loss, idling 3 W
Power loss, nominal load 40 W
Protection against over-heating Yes
Protection against reverse voltages from the load 33…34 V DC
Protection degree IP20
Short-circuit protection Yes
Start-up ≥ -40 °C
Surge voltage category III
