Weidmuller AFS 2.5 CF 2C BK 2466530000 Fuse Terminal

Weidmuller AFS 2.5 CF 2C BK is A-Series terminal block, Fuse terminal, PUSH IN, 2.5 mm², 500 V, 10 A, black,order no. Is 2466530000. Weidmuller’s A-Series terminal blocks,increase your efficiency during installations without compromising on safety. The innovative PUSH IN technology reduces connection times for solid conductors and conductors with crimped-on wire-end ferrules by up to 50 percent compared to tension clamp terminals. The conductor is simply inserted into the contact point as far as the stop and that’s it – you have a safe, gas-tight connection. Even stranded-wire conductors can be connected without any problem and without the need for special tools. Safe and reliable connections are crucial, especially under harsh conditions, such as those encountered in the process industry. PUSH IN technology guarantees optimal contact security and ease of handling, even in demanding applications.

Products Details

Spring connection with PUSH IN technology (A-Series) Time saving 1.Mounting foot makes unlatching the terminal block easy 2. Clear distinction made between all functional areas 3.Easier marking and wiring Space saving design 1.Slim design creates a large amount of space in the panel 2.High wiring density despite less space being required on the terminal rail Safety 1.Optical and physical separation of operation and conductor entry 2.Vibration-resistant, gas-tight connection with copper power rails and stainless steel spring Flexibility 1.Large marking surfaces make maintenance work easier 2.Clip-in foot compensates for differences in terminal rail dimensions
Version Fuse terminal, PUSH IN, 2.5 mm², 500 V, 10 A, black
Order No. 2466530000
Type AFS 2.5 CF 2C BK
GTIN (EAN) 4050118480825
Qty. 50 pc(s).

Depth 37.65 mm
Depth (inches) 1.482 inch
Depth including DIN rail 38.4 mm
Height 77.5 mm
Height (inches) 3.051 inch
Width 5.1 mm
Width (inches) 0.201 inch
Net weight 9.124 g

Order No. Type
2466610000 AFS 2.5 CF 2C 12V BK
2466600000 AFS 2.5 CF 2C 24V BK
