Weidmuller A4C 4 2051500000 Feed-through Terminal

Weidmuller A4C 4 is A-Series terminal block, Feed-through terminal, PUSH IN, 4 mm², 800 V, 32 A, dark beige,order no. is 2051500000. Weidmuller’s A-Series terminal blocks,increase your efficiency during installations without compromising on safety. The innovative PUSH IN technology reduces connection times for solid conductors and conductors with crimped-on wire-end ferrules by up to 50 percent compared to tension clamp terminals. The conductor is simply inserted into the contact point as far as the stop and that’s it – you have a safe, gas-tight connection. Even stranded-wire conductors can be connected without any problem and without the need for special tools. Safe and reliable connections are crucial, especially under harsh conditions, such as those encountered in the process industry. PUSH IN technology guarantees optimal contact security and ease of handling, even in demanding applications.

Products Details

Spring connection with PUSH IN technology (A-Series) Time saving 1.Mounting foot makes unlatching the terminal block easy 2. Clear distinction made between all functional areas 3.Easier marking and wiring Space saving design 1.Slim design creates a large amount of space in the panel 2.High wiring density despite less space being required on the terminal rail Safety 1.Optical and physical separation of operation and conductor entry 2.Vibration-resistant, gas-tight connection with copper power rails and stainless steel spring Flexibility 1.Large marking surfaces make maintenance work easier 2.Clip-in foot compensates for differences in terminal rail dimensions
Version Feed-through terminal, PUSH IN, 4 mm², 800 V, 32 A, dark beige
Order No. 2051500000
Type A4C 4
GTIN (EAN) 4050118411621
Qty. 50 pc(s).

Depth 39.5 mm
Depth (inches) 1.555 inch
Depth including DIN rail 40.5 mm
Height 87.5 mm
Height (inches) 3.445 inch
Width 6.1 mm
Width (inches) 0.24 inch
Net weight 15.06 g

Order No. Type
2051310000 A2C 4 BK
2051210000 A2C 4 BL
2051180000 A2C 4
2051240000 A3C 4
2534290000 A3C 4 BR
2534360000 A3C 4 DBL
2051500000 A4C 4
2051580000 A4C 4 GN
2051670000 A4C 4 LTGY
