Compact and flexible housing design to fit into confined spaces
Web-based GUI for easy device configuration and management
Security features based on IEC 62443
IP40-rated metal housing
| Standards | IEEE 802.3 for10BaseTIEEE 802.3u for 100BaseT(X) IEEE 802.3ab for 1000BaseT(X) IEEE 802.3z for 1000BaseX IEEE 802.1Q for VLAN Tagging IEEE 802.1p for Class of Service IEEE 802.1D-2004 for Spanning Tree Protocol IEEE 802.1wfor Rapid Spanning Tree Protocol |
| 10/100/1000BaseT(X) Ports (RJ45 connector) | 6Auto negotiation speed Full/Half duplex mode Auto MDI/MDI-X connection |
| Combo Ports (10/100/1000BaseT(X) or 100/1000BaseSFP+) | 2Auto negotiation speed Full/Half duplex mode Auto MDI/MDI-X connection |
| Alarm Contact Channels | 1, Relay output with current carrying capacity of1 A@24 VDC |
| Buttons | Reset button |
| Digital Input Channels | 1 |
| Digital Inputs | +13 to +30 V for state 1 -30 to +3 V for state 0 Max. input current: 8 mA |
| Connection | 2 removable 4-contact terminal block(s) |
| Input Voltage | 12to48 VDC, Redundant dual inputs |
| Operating Voltage | 9.6 to 60 VDC |
| Input Current | 1.72A@12 VDC |
| Overload Current Protection | Supported |
| Reverse Polarity Protection | Supported |
| Housing | Metal |
| IP Rating | IP40 |
| Dimensions | 36x135x115 mm (1.42 x 5.32 x 4.53 in) |
| Weight | 787g(1.74lb) |
| Installation | DIN-rail mounting, Wall mounting (with optional kit) |
| Operating Temperature | -10to 60°C (14to140°F) |
| Storage Temperature (package included) | -40 to 85°C (-40 to185°F) |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
