| 10/100BaseT(X) Ports (RJ45 connector) | 1 |
| Magnetic Isolation Protection | 1.5 kV (built-in) |
| Standards | IEEE 802.3 for10BaseTIEEE 802.3u for 100BaseT(X) |
| Input Current | NPort W2150A/W2150A-T: 179 mA@12 VDCNPort W2250A/W2250A-T: 200 mA@12 VDC |
| Input Voltage | 12to48 VDC |
| Housing | Metal |
| Installation | Desktop, DIN-rail mounting (with optional kit), Wall mounting |
| Dimensions (with ears, without antenna) | 77x111 x26 mm (3.03x4.37x 1.02 in) |
| Dimensions (without ears or antenna) | 100x111 x26 mm (3.94x4.37x 1.02 in) |
| Weight | NPort W2150A/W2150A-T: 547g(1.21 lb)NPort W2250A/W2250A-T: 557 g (1.23 lb) |
| Antenna Length | 109.79 mm (4.32 in) |
| Operating Temperature | Standard Models: 0 to 55°C (32 to 131°F)Wide Temp. Models: -40 to 75°C (-40 to 167°F) |
| Storage Temperature (package included) | -40 to 75°C (-40 to167°F) |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
| Model Name | No. of serial ports | WLAN Channels | Input Current | Operating Temp. | Power Adapter in Box | Notes |
| NPortW2150A-CN | 1 | China bands | 179 mA@12VDC | 0 to 55°C | Yes (CN plug) | 一 |
| NPortW2150A-EU | 1 | Europe bands | 179 mA@12VDC | 0 to 55°C | Yes (EU/UK/AU plug) | 一 |
| NPortW2150A-EU/KC | 1 | Europe bands | 179 mA@12VDC | 0 to 55°C | Yes (EU plug) | KC certificate |
| NPortW2150A-JP | 1 | Japan bands | 179 mA@12VDC | 0 to 55°C | Yes (JP plug) | 一 |
| NPortW2150A-US | 1 | US bands | 179 mA@12VDC | 0 to 55°C | Yes (US plug) | 一 |
| NPortW2150A-T-CN | 1 | China bands | 179 mA@12VDC | -40 to 75°C | No | 一 |
| NPortW2150A-T-EU | 1 | Europe bands | 179 mA@12VDC | -40 to 75°C | No | 一 |
| NPortW2150A-T-JP | 1 | Japan bands | 179 mA@12VDC | -40 to 75°C | No | 一 |
| NPortW2150A-T-US | 1 | US bands | 179 mA@12VDC | -40 to 75°C | No | 一 |
| NPortW2250A-CN | 2 | China bands | 200 mA@12VDC | 0 to 55°C | Yes (CN plug) | 一 |
| NPort W2250A-EU | 2 | Europe bands | 200 mA@12VDC | 0 to 55°C | Yes (EU/UK/AU plug) | 一 |
| NPortW2250A-EU/KC | 2 | Europe bands | 200 mA@12VDC | 0 to 55°C | Yes (EU plug) | KC certificate |
| NPortW2250A-JP | 2 | Japan bands | 200 mA@12VDC | 0 to 55°C | Yes (JP plug) | 一 |
| NPortW2250A-US | 2 | US bands | 200 mA@12VDC | 0 to 55°C | Yes (US plug) | 一 |
| NPortW2250A-T-CN | 2 | China bands | 200 mA@12VDC | -40 to 75°C | No | 一 |
| NPortW2250A-T-EU | 2 | Europe bands | 200 mA@12VDC | -40 to 75°C | No | 一 |
| NPortW2250A-T-JP | 2 | Japan bands | 200 mA@12VDC | -40 to 75°C | No | 一 |
| NPortW2250A-T-US | 2 | US bands | 200 mA@12VDC | -40 to 75°C | No | 一 |
