IEEE 802.3af-compliant PoE power device equipment
Speedy 3-step web-based configuration
Surge protection for serial, Ethernet, and power
COM port grouping and UDP multicast applications
Screw-type power connectors for secure installation
Real COM and TTY drivers for Windows, Linux, and macOS
Standard TCP/IP interface and versatile TCP and UDP operation modes
Ethernet Interface| 10/100BaseT(X) Ports (RJ45 connector) | 1 |
| Magnetic Isolation Protection | 1.5 kV (built-in) |
| Standards | PoE (IEEE 802.3af) |
| Input Current | DC Jack I/P: 125 mA@12 VDCPoE I/P:180mA@48 VDC |
| Input Voltage | 12to48 VDC (supplied by power adapter), 48 VDC (supplied by PoE) |
| No. of Power Inputs | 1 |
| Source of Input Power | Power input jack PoE |
| Housing | Metal |
| Dimensions (with ears) | 100x111 x26 mm (3.94x4.37x 1.02 in) |
| Dimensions (without ears) | 77x111 x26 mm (3.03x4.37x 1.02 in) |
| Weight | 300 g (0.66 lb) |
| Operating Temperature | NPort P5150A: 0 to 60°C (32 to 140°F)NPort P5150A-T:-40 to 75°C (-40 to 167°F) |
| Storage Temperature (package included) | -40 to 75°C (-40 to167°F) |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
| Model Name | Operating Temp. | Baudrate | Serial Standards | No. of Serial Ports | Input Voltage |
| NPort P5150A | 0 to 60°C | 50 bps to 921.6 kbps | RS-232/422/485 | 1 | 12-48 VDC by power adapter or 48 VDC by PoE |
| NPort P5150A-T | -40 to 75°C | 50 bps to 921.6 kbps | RS-232/422/485 | 1 | 12-48 VDC by power adapter or 48 VDC by PoE |
