Ethernet Interface
| 10/100BaseT(X) Ports (RJ45 connector) | 2 (1 IP, Ethernet cascade, NPort IA-5150/5150I/5250/5250I) |
| Magnetic Isolation Protection | 1.5 kV (built-in)
|
| 100BaseFX Ports (multi-mode SC connector) | NPort IA-5000-M-SC Models: 1 NPort IA-5000-M-ST Models: 1 NPort IA-5000-S-SC Models: 1
|
| 100BaseFX Ports (single-mode SC connector) | NPort IA-5000-S-SC Models: 1 |
| Housing | Plastic |
| IP Rating | IP30 |
| Dimensions | 29 x 89.2 x118.5 mm (0.82 x 3.51 x 4.57 in) |
| Weight | NPort IA-5150: 360 g (0.79 lb) NPort IA-5250: 380 g (0.84 lb) |
| Installation | DIN-rail mounting |
| Operating Temperature | Standard Models: 0 to 60°C (32 to 140°F) Wide Temp. Models: -40 to 75°C (-40 to 167°F) |
| Storage Temperature (package included) | -40 to 85°C (-40 to167°F) |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
| Model Name | No. of Ethernet Ports | Ethernet Port Connector | Operating Temp. | No. of Serial Ports | Serial Isolation | Certification: Hazardous Locations |
| NPort IA-5150 | 2 | RJ45 | 0 to 55°C | 1 | - | ATEX, C1D2, IECEx |
| NPort IA-5150-T | 2 | RJ45 | -40 to 75°C | 1 | - | ATEX, C1D2, IECEx |
| NPort IA-5150I | 2 | RJ45 | 0 to 55°C | 1 | 2kV | ATEX, C1D2, IECEx |
| NPort IA-5150I-T | 2 | RJ45 | -40 to 75°C | 1 | 2kV | ATEX, C1D2, IECEx |
| NPort IA-5150-M-SC | 1 | Multi-Mode SC | 0 to 55°C | 1 | - | ATEX, C1D2, IECEx |
| NPort IA-5150-M-SC-T | 1 | Multi-Mode SC | -40 to 75°C | 1 | - | ATEX, C1D2, IECEx |
| NPort IA-5150I-M-SC | 1 | Multi-Mode SC | 0 to 55°C | 1 | 2kV | ATEX, C1D2, IECEx |
| NPort IA-5150I-M-SC-T | 1 | Multi-Mode SC | -40 to 75°C | 1 | 2kV | ATEX, C1D2, IECEx |
| NPort IA-5150-S-SC | 1 | Single-mode SC | 0 to 55°C | 1 | - | ATEX, C1D2, IECEx |
| NPort IA-5150-S-SC-T | 1 | Single-mode SC | -40 to 75°C | 1 | - | ATEX, C1D2, IECEx |
| NPort IA-5150I-S-SC | 1 | Single-mode SC | 0 to 55°C | 1 | 2kV | ATEX, C1D2, IECEx |
| NPort IA-5150I-S-SC-T | 1 | Single-mode SC | -40 to 75°C | 1 | 2kV | ATEX, C1D2, IECEx |
| NPort IA-5150-M-ST | 1 | Multi-ModeST | 0 to 55°C | 1 | - | ATEX, C1D2, IECEx |
| NPort IA-5150-M-ST-T | 1 | Multi-ModeST | -40 to 75°C | 1 | - | ATEX, C1D2, IECEx |
| NPort IA-5250 | 2 | RJ45 | 0 to 55°C | 2 | - | ATEX, C1D2, IECEx |
| NPort IA-5250-T | 2 | RJ45 | -40 to 75°C | 2 | - | ATEX, C1D2, IECEx |
| NPort IA-5250I | 2 | RJ45 | 0 to 55°C | 2 | 2kV | ATEX, C1D2, IECEx |
| NPort IA-5250I-T | 2 | RJ45 | -40 to 75°C | 2 | 2kV | ATEX, C1D2, IECEx |
