Secure operation modes for Real COM, TCP Server, TCP Client, Pair Connection, Terminal, and Reverse Terminal
Supports nonstandard baudrates with high precision
NPort 6250: Choice of network medium: 10/100BaseT(X) or 100BaseFX
Enhanced remote configuration with HTTPS and SSH
Port buffers for storing serial data when the Ethernet is offline
Supports IPv6
Generic serial commands supported in Command-by-Command mode
Security features based on IEC 62443
MemorySD Slot | NPort 6200 Models: Up to 32 GB (SD 2.0 compatible) |
10/100BaseT(X) Ports (RJ45 connector) | NPort 6150/6150-T: 1 NPort 6250/6250-T: 1 Auto MDI/MDI-X connection |
100BaseFX Ports (multi-mode SC connector) | NPort 6250-M-SC Models: 1 |
100BaseFX Ports (single-mode SC connector) | NPort 6250-S-SC Models: 1 |
Magnetic Isolation Protection | 1.5 kV (built-in)
|
Input Current | NPort 6150/6150-T: 12-48 Vdc, 285 mA NPort 6250/6250-T: 12-48 Vdc, 430 mA NPort 6250-M-SC/6250-M-SC-T: 12-48 Vdc, 430 mA NPort 6250-S-SC/6250-S-SC-T: 12-48 Vdc, 430 mA |
Input Voltage | 12to48 VDC |
Housing | Metal |
Dimensions (with ears) | NPort 6150 Models: 90 x100.4x29 mm (3.54x3.95x 1.1 in) NPort 6250 Models:89x111 x 29 mm (3.50 x 4.37 x1.1 in) |
Dimensions (without ears) | NPort 6150 Models: 67 x100.4 x 29 mm (2.64 x 3.95 x1.1 in) NPort 6250 Models: 77x111 x 29 mm (3.30 x 4.37 x1.1 in) |
Weight | NPort 6150 Models: 190g (0.42 lb) NPort 6250 Models: 240 g (0.53 lb) |
Installation | Desktop, DIN-rail mounting (with optional kit), Wall mounting |
Operating Temperature | Standard Models: 0 to 55°C (32 to 131°F) Wide Temp. Models: -40 to 75°C (-40 to 167°F) |
Storage Temperature (package included) | -40 to 75°C (-40 to167°F) |
Ambient Relative Humidity | 5 to 95% (non-condensing) |
Model Name | Ethernet Interface | No. of Serial Ports | SD Card Support | Operating Temp. | Traffic Control Certificates | Power Supply Included |
NPort6150 | RJ45 | 1 | - | 0 to 55°C | NEMATS2 | / |
NPort6150-T | RJ45 | 1 | - | -40 to 75°C | NEMATS2 | - |
NPort6250 | RJ45 | 2 | Up to 32 GB (SD 2.0 compatible) | 0 to 55°C | NEMA TS2 | / |
NPort 6250-M-SC | Multi-modeSC fiber connector | 2 | Up to 32 GB (SD 2.0 compatible) | 0 to 55°C | NEMA TS2 | / |
