Small size for easy installation
Real COM and TTY drivers for Windows, Linux, and macOS
Standard TCP/IP interface and versatile operation modes
Easy-to-use Windows utility for configuring multiple device servers
SNMP MIB-II for network management
Configure by Telnet, web browser, or Windows utility
Adjustable pull high/low resistor for RS-485 ports
Ethernet Interface| 10/100BaseT(X) Ports (RJ45 connector) | 1 |
| Magnetic Isolation Protection | 1.5 kV (built-in)
|
| Configuration Options | Serial Console (NPort 5110/5110-T/5150 only), Windows Utility, Telnet Console, Web Console (HTTP) |
| Management | DHCP Client, IPv4,SMTP, SNMPv1,Telnet, DNS, HTTP, ARP, BOOTP, UDP, TCP/IP, ICMP |
| Windows Real COM Drivers | Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7/8/8.1/10/11 (x86/x64),Windows 2008 R2/2012/2012 R2/2016/2019 (x64), Windows Server 2022, Windows Embedded CE 5.0/6.0, Windows XP Embedded |
| Linux Real TTY Drivers | Kernel versions: 2.4.x, 2.6.x, 3.x, 4.x, and 5.x |
| Fixed TTY Drivers | macOS 10.12, macOS 10.13, macOS 10.14, macOS 10.15, SCO UNIX, SCO OpenServer, UnixWare 7, QNX 4.25, QNX6, Solaris 10, FreeBSD, AIX 5.x, HP-UX 11i, Mac OS X |
| Android API | Android 3.1.x and later |
| MIB | RFC1213, RFC1317 |
| Input Current | NPort 5110/5110-T: 128 mA@12 VDCNPort 5130/5150: 200 mA@12 VDC |
| Input Voltage | 12to48 VDC |
| No. of Power Inputs | 1 |
| Source of Input Power | Power input jack |
| Housing | Metal |
| Dimensions (with ears) | 75.2x80x22 mm (2.96x3.15x0.87 in) |
| Dimensions (without ears) | 52x80x 22 mm (2.05 x3.15x 0.87 in) |
| Weight | 340 g (0.75 lb) |
| Installation | Desktop, DIN-rail mounting (with optional kit), Wall mounting |
| Operating Temperature | Standard Models: 0 to 55°C (32 to 131°F)Wide Temp. Models: -40 to 75°C (-40 to 167°F) |
| Storage Temperature (package included) | -40 to 75°C (-40 to167°F) |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
| Model Name | Operating Temp. | Baudrate | Serial Standards | Input Current | Input Voltage |
| NPort5110 | 0 to 55°C | 110 bps to 230.4 kbps | RS-232 | 128.7 mA@12VDC | 12-48 VDC |
| NPort5110-T | -40 to 75°C | 110 bps to 230.4 kbps | RS-232 | 128.7 mA@12VDC | 12-48 VDC |
| NPort5130 | 0 to 55°C | 50 bps to 921.6 kbps | RS-422/485 | 200 mA @12 VDC | 12-48 VDC |
| NPort5150 | 0 to 55°C | 50 bps to 921.6 kbps | RS-232/422/485 | 200 mA @12 VDC | 12-48 VDC |
