The MGate W5108/W5208 gateways are an ideal choice for connecting Modbus serial devices to a wireless LAN, or DNP3 serial to DNP3 IP through a wireless LAN. With IEEE 802.11a/b/g/n support, you can use fewer cables in difficult wiring environments, and for secure data transmission, the MGate W5108/W5208 gateways support WEP/WPA/WPA2. The gateways' rugged design makes them suitable for industrial applications, including oil and gas, power, process automation, and factory automation.
Supports Modbus serial tunneling communications through an 802.11 network Supports DNP3 serial tunneling communications through an 802.11 network Accessed by up to 16 Modbus/DNP3 TCP masters/clients Connects up to 31 or 62 Modbus/DNP3 serial slaves Embedded traffic monitoring/diagnostic information for easy troubleshooting microSD card for configuration backup/duplication and event logs Serial port with 2 kV isolation protection -40 to 75°C wide operating temperature models available Supports 2 digital inputs and 2 digital outputs Supports redundant dual DC power inputs and 1 relay output Security features based on IEC 62443Ethernet Interface
10/100BaseT(X) Ports (RJ45 connector)
1
Magnetic Isolation Protection
1.5 kV (built-in)
Power Parameters
Input Voltage
9 to 60 VDC
Input Current
202 mA@24VDC
Power Connector
Spring-type Euroblock terminal
Physical Characteristics
Housing
Metal
IP Rating
IP30
Dimensions
MGateW5108 Models: 45.8 x105 x134 mm (1.8x4.13x5.28 in)MGate W5208 Models: 59.6 x101.7x134x mm (2.35 x4x5.28 in)
Weight
MGate W5108 Models: 589 g (1.30 lb)MGate W5208 Models: 738 g (1.63 lb)
Environmental Limits
Operating Temperature
Standard Models: 0 to 60°C (32 to 140°F)Wide Temp. Models: -40 to 75°C (-40 to 167°F)
