Front-end intelligence with Click&Go control logic, up to 24 rules Active communication with MX-AOPC UA Server Saves time and wiring costs with peer-to-peer communications Supports SNMP v1/v2c/v3 Friendly configuration via web browser Simplifies I/O management with MXIO library for Windows or Linux Wide operating temperature models available for -40 to 75°C (-40 to 167°F) environmentsControl Logic

Language

Click&Go

Input/Output Interface

Digital Input Channels	ioLogikE2210Series: 12 ioLogikE2212Series:8 ioLogikE2214Series:6
Digital Output Channels	ioLogik E2210/E2212 Series: 8ioLogik E2260/E2262 Series: 4
Configurable DIO Channels (by software)	ioLogik E2212 Series: 4ioLogik E2242 Series: 12
Relay Channels	ioLogikE2214Series:6
Analog Input Channels	ioLogik E2240 Series: 8ioLogik E2242 Series: 4
Analog Output Channels	ioLogik E2240 Series: 2
RTD Channels	ioLogik E2260 Series: 6
Thermocouple Channels	ioLogik E2262 Series: 8
Buttons	Reset button
Rotary Switch	0to9
Isolation	3kVDC or2kVrms

Digital Inputs

Connector		Screw-fastened Euroblock terminal
Sensor Type		ioLogik E2210 Series: Dry Contact and Wet Contact (NPN)ioLogik E2212/E2214/E2242 Series: Dry Contact and Wet Contact (NPN or PNP)
I/O Mode		DI or event counter
Dry Contact		On: short to GNDOff: open
Wet Contact (DI to GND)		On: 0 to 3 VDC Off: 10 to 30 VDC
Counter Frequency		900 Hz
Digital Filtering Time Interval		Software configurable
Points per COM		ioLogik E2210 Series: 12 channels ioLogik E2212/E2242 Series: 6 channels ioLogik E2214 Series: 3 channels

Power Parameters

Power Connector	Screw-fastened Euroblock terminal
No. of Power Inputs	1
Input Voltage	12to36 VDC
Power Consumption	ioLogik E2210 Series: 202 mA @ 24 VDC ioLogik E2212 Series: 136 mA@ 24 VDC ioLogik E2214Series: 170 mA@ 24 VDC ioLogik E2240 Series: 198 mA@ 24 VDC ioLogik E2242 Series: 178 mA@ 24 VDC ioLogik E2260 Series: 95 mA @ 24 VDC ioLogik E2262 Series: 160 mA @ 24 VDC

Physical Characteristics

Dimensions	115x79x 45.6 mm (4.53 x3.11 x1.80 in)
Weight	250 g (0.55 lb)
Installation	DIN-rail mounting, Wall mounting
Wiring	I/O cable, 16to 26AWG Power cable, 16to26 AWG
Housing	Plastic

Environmental Limits

Operating Temperature	Standard Models: -10 to 60°C (14to 140°F) Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Storage Temperature (package included)	-40 to 85°C (-40 to185°F)
Ambient Relative Humidity	5 to 95% (non-condensing)
Altitude	2000 m

MOXA ioLogik E2212 Available Models

Model Name	Input/Output Interface	Digital Input Sensor Type	Analog Input Range	Operating Temp.
ioLogikE2210	12xDI,8xDO	Wet Contact (NPN), Dry Contact	-	-10 to 60°C
ioLogikE2210-T	12xDI,8xDO	Wet Contact (NPN), Dry Contact	-	-40 to 75°C
ioLogik E2212	8xDI,4xDIO,8xDO	Wet Contact (NPN or PNP), Dry Contact	-	-10 to 60°C
ioLogikE2212-T	8 x DI, 4 x DIO, 8 x DO	Wet Contact (NPN or PNP), Dry Contact	-	-40 to 75°C
ioLogikE2214	6x DI, 6x Relay	Wet Contact (NPN or PNP), Dry Contact	-	-10 to 60°C
ioLogikE2214-T	6x DI, 6x Relay	Wet Contact (NPN or PNP), Dry Contact	-	-40 to 75°C
ioLogik E2240	8xAI, 2xAO	-	±150 mV, ±500 mV, ±5 V, ±10 V, 0-20 mA, 4-20 mA	-10 to 60°C
ioLogik E2240-T	8xAI,2xAO	-	±150 mV, ±500 mV, ±5 V, ±10 V, 0-20 mA, 4-20 mA	-40 to 75°C
ioLogik E2242	12xDIO,4xAI	Wet Contact (NPN or PNP), Dry Contact	±150 mV, 0-150 mV, ±500 mV, 0-500 mV, ±5 V, 0-5 V, ±10 V, 0-10 V, 0-20 mA, 4-20 mA	-10 to 60°C
ioLogik E2242-T	12xDIO,4xAI	Wet Contact (NPN or PNP), Dry Contact	±150 mV, 0-150 mV, ±500 mV, 0-500 mV, ±5 V, 0-5 V, ±10 V, 0-10 V, 0-20 mA, 4-20 mA	-40 to 75°C
ioLogik E2260	4 x DO, 6 x RTD	-	-	-10 to 60°C
ioLogik E2260-T	4 x DO, 6 x RTD	-	-	-40 to 75°C
ioLogik E2262	4xDO,8xTC	-	-	-10 to 60°C
ioLogik E2262-T	4xDO,8xTC	-	-	-40 to 75°C
