Supports 1000Base-SX/LX with SC connector or SFP slot Link Fault Pass-Through (LFPT) 10K jumbo frame Redundant power inputs -40 to 75°C operating temperature range (-T models) Supports Energy-Efficient Ethernet (IEEE 802.3az) Ethernet Interface

10/100/1000BaseT(X) Ports (RJ45 connector)	1
100/1000BaseSFP Ports	IMC-21GA models: 1
1000BaseSX Ports (multi-mode SC connector)	IMC-21GA-SX-SC models: 1
1000BaseLX Ports (single-mode SC connector)Magnetic Isolation Protection	IMC-21GA-LX-SC models: 1
Magnetic Isolation Protection	1.5 kV (built-in)

Power Parameters

Input Current	284.7 mA@12to 48 VDC
Input Voltage	12 to 48 VDC
Overload Current Protection	Supported
Power Connector	Terminal block
Power Consumption	284.7 mA@12to 48 VDC

Physical Characteristics

Housing	Metal
Dimensions	30x125x79 mm(1.19x4.92x3.11 in)
Weight	170g(0.37 lb)
Installation	DIN-rail mounting

Environmental Limits

Operating Temperature	Standard Models: -10 to 60°C (14to 140°F) Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Storage Temperature (package included)	-40 to 75°C (-40 to167°F)
Ambient Relative Humidity	5 to 95% (non-condensing)

Standards and Certifications

EMC	EN 55032/24
EMI	CISPR 32, FCC Part 15B Class A
EMS	IEC 61000-4-2 ESD: Contact: 6 kV; Air:8 kVIEC 61000-4-3 RS:80 MHz to 1 GHz: 10 V/mIEC 61000-4-4 EFT: Power: 2 kV; Signal: 1 kVIEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV IEC 61000-4-6 CS: 150 kHz to 80 MHz: 10 V/m; Signal: 10 V/m IEC 61000-4-8 PFMF IEC 61000-4-11
Environmental Testing	IEC 60068-2-1IEC 60068-2-2IEC 60068-2-3
Safety	EN 60950-1, UL60950-1
Vibration	IEC 60068-2-6

MTBF

Time	2,762,058 hrs
Standards	MIL-HDBK-217F

MOXA IMC-21GA-LX-S Available Models

Model Name	Operating Temp.	Fiber Module Type
IMC-21GA	-10 to 60°C	SFP
IMC-21GA-T	-40 to 75°C	SFP
IMC-21GA-SX-SC	-10 to 60°C	Multi-mode SC
IMC-21GA-SX-SC-T	-40 to 75°C	Multi-mode SC
IMC-21GA-LX-SC	-10 to 60°C	Single-mode SC
IMC-21GA-LX-SC-T	-40 to 75°C	Single-mode SC
